Name Description Value/range Explanation Default
value
Monitoring On
* Start of monitoring of strings in all
groups 0:00 a.m. to
11:59 p.m. ‒ 0
Monitoring Off
* End of monitoring of strings in all
groups 0:00 a.m. to
11:59 p.m. ‒ 0
Kommando** Stop If you wish to use this function,
contact us (see Section 13,
page 154). 0
Mess
Offset1
Offset2
Diag
Reset Err.Cnt.
StoreCalibData
LoadCalibData
Watchdog Test
Surge Arrester1
* Alarm contact (e.g. theft protec-
tion for Sunny String-Monitor) Activ High Contact activated when volt-
age is present 0
Activ Low Contact activated when no
voltage is present
Deactivated Contact deactivated
Surge Arrester2
* Alarm contact Activ High Contact activated when volt-
age is present 0
Activ Low Contact activated when no
voltage is present
Deactivated Contact deactivated
* To change these parameters, you must enter the installer password.
** These parameters are only visible after entering the installer password.
11.2.4 Zone Monitoring
Name Description Value/range Explanation Default
value
DcCfg.AmpMax[1] Maximum current of input
1 0 A to 500 A ‒ 0 A
DcCfg.AmpMax[2] Maximum current of input
2 0 A to 500 A ‒ 0 A
DcCfg.AmpMax[3] Maximum current of input
3 0 A to 500 A ‒ 0 A
