Minimum clearances for one inverter to be installed in electrical equipment rooms
The minimum passage width between the open door of the inverter and the next fixed obstacle must be maintained.
The minimum passage width must comply with national standards.
Figure 46: Minimum clearances for one inverter in an electrical equipment room
Position Designation
A Minimum passage width
B Inverter
Minimum clearances for two inverters to be installed in electrical equipment rooms
Danger to life due to blocked escape routes
In hazardous situations, blocked escape routes can lead to death or serious injury. Opening the doors of two
products located opposite each other can block the escape route. It is imperative that the escape route is freely
accessible at all times.
• An escape route must be available at all times. Make sure the minimum passage width of the escape route
meets local standards.
• Do not place any objects in the escape route area.
• Remove all tripping hazards from escape routes.
