Name Description Value/range Explanation Default
value
QoDQ-Var** Reactive power setpoint
in the operating mode
"Q at Night" −245 kVAr to
+245 kVAr Sunny Central 500CP XT 0 kVAr
−310 kVAr to
+310 kVAr Sunny Central 630CP XT
−346 kVAr to
+346 kVAr Sunny Central 720CP XT
−365 kVAr to
+365 kVAr Sunny Central 760CP XT
−385 kVAr to
+385 kVAr Sunny Central 800CP XT
−409 kVAr to
+409 kVAr Sunny Central 850CP XT
−433 kVAr to
+433 kVAr Sunny Central 900CP XT
Q-VArNom Reactive power in % −100 % … +100 % ‒ 0 %
QoDQ-
VArNom Reactive power in % in
the operating state
"Q at Night" −100 % … +100 % ‒ 0 %
PF-PF Displacement power fac-
tor cos φ
The lower limit is defined
by the parameter PFAb-
sMin.
0.5 … 1 ‒ 1
PF-PFExt Excitation of the dis-
placement power factor
cos φ OvExt Overexcited OvExt
UnExt Underexcited
PF-PFStr** Displacement power fac-
tor cos φ at characteristic
curve point 1
The lower limit is defined
by the parameter PFAb-
sMin.
0.5 … 1 ‒ 0.9
PF-PFExtStr** Excitation of the dis-
placement power factor
cos φ at characteristic
curve point 1 OvExt Overexcited OvExt
UnExt Underexcited
