4.1.2 Display Flowchart

Monitor Mode, Parameter Mode and Parameter Setting Mode

1. When the power is applied to the AC servo drive, the digital keypad will execute communication

initial setup for approximately two seconds (9600bps & 7,N,2 Modbus ASCII) first, and then enter

into the monitor mode.

2. In monitor mode, pressing UP or DOWN arrow key can switch monitor parameter code.

3. In monitor mode, pressing MODE key can enter into parameter mode, pressing the SHIFT key

can switch parameter group and pressing UP or DOWN arrow key can change parameter group

code.

4. In parameter mode, system will enter into the parameter setting mode immediately after the SET

key is pressed. The LCD display will display the corresponding setting value of this parameter

simultaneously. Then, users can use UP or DOWN arrow key to change parameter value or press

MODE key to exit and return back to the parameter mode.

5. In parameter setting mode, users can move the cursor to left by pressing the SHIFT key and

change the parameter settings (blinking digits) by pressing the UP or DOWN arrow key.

6. After the setting value change is completed, press SET key to save parameter settings or execute

command.

7. When the parameter setting is completed, LCD display will show the end code “-SET END-“ and

automatically return back to parameter mode.

Figure 4.2

STS01:Fb REV
0 rev

STS02:CMD PULSE
0 pulse

STS15:IGBT temp
33 degC

P0-00:VER
0.005

P0-01:ALE
0

P0-02:STS
0

P1-00:PTT
2

P1-01:CTL

P1-02:PSTL
0

P2-00:KPP
70 rad/s

P2-01:PPR
100 %

P2-02:PFG
50 %

P3-00:ADR
1

P3-01:BRT
3 bps

P3-02:PTL
0

P4-00:ASH1
1

P4-01:ASH2
1

P4-02:ASH3
1

P8-00:VERSION
1.001

P8-01:MISC FUN
1

P8-05:KPD ID
255

10000

10001

SET END

SET

GROUP0

STS00:Fb PULSE
0 pulse

GROUP1

GROUP2

GROUP3

GROUP4

GROUP8

SET

Edit Setting Values

MODE

SHIFT

Save Setting Values

Parameter Mode

Monitor Mode

Parameter

Setting Mode
