background image

Chapter 3 Connections and Wiring|ASDA-B Series

3-2

Revision February 2008, Doc. Name: 2006PDD23000009

3.1.2 Servo Drive Connectors and Terminals

Terminal

Identification

Terminal

Description

Notes

R, S, T

Main circuit terminal

The Main Circuit Terminal is used to supply the servo with
line power. If a single-phase supply, is used connect the R
and S terminals to power. If 3-phase, connect all three R, S,
& T terminals.

Used to connect servo motor

Terminal Symbol

Wire Color

U Red

V White

W Black

U, V, W
FG

Servo motor output

FG Green

Internal resistor

Ensure the circuit is closed between P
and D, and the circuit is open between
P and C.

External resistor

Connect regenerative resistor to P and
C, and ensure an open circuit between
P and D.

P, D, C

Regenerative
resistor terminal

Only 750W and above servo drives are provided with built-
in regenerative resistors. Ensure to leave the circuit closed
between P and D when using a built-in (internal)
regenerative resistor.

two places Ground terminal

Used to connect grounding wire of power supply and servo
motor.

CN1

I/O connector

Used to connect external controllers. Please refer to section
3.3 for details.

Used to connect encoder of servo motor. Please refer to
section 3.4 for details.

Terminal Symbol

Wire Color

A Black

/A Black/Red

B White

/B White/Red

Z Orange

/Z Orange/Red

+5V Brown

&

Brown/White

CN2

Encoder connector

GND

Blue & Blue/White

CN3

Communication
connector

Used to connect PC or keypad. Please refer to section 3.5
for details.

NOTE

1) U, V ,W , CN1, CN2, CN3 terminals provide short circuit protection.
