Delta Electronics AC Servo Drive ASDA-B User Manual
Page 31
Chapter 3 Connections and Wiring|ASDA-B Series
3-6
Revision February 2008, Doc. Name: 2006PDD23000009
Motor Model Name
U, V, W / Electromagnetic Brake Connector
Terminal
Identification
ECMA-G31303
S (300W)
ECMA-E31305
S (500W)
ECMA-G31306
S (600W)
ECMA-G31309
S (900W)
ECMA-C31010
S (1000W)
ECMA-E31310
S (1000W)
ECMA-E31315
S (1500W)
ECMA-C31020
S (2000W)
ECMA-E31320
S (2000W)
3106A-20-18S
C
ECMA-E31820 S (2000W)
3106A-24-11S
D
Terminal
Identification
U
(Red)
V
(White)
W
(Black)
CASE GROUND
(Green)
BRAKE1
BRAKE2
A 1 2 3
4
- -
B 1 2 4
5
3 6
C F I B
E
G H
D D E F
G
A B
NOTE
1) The coil of brake has no polarity. The names of terminal identification are BRAKE1 and BRAKE2.
2) The power supply for brake is DC24V. Never use it for VDD, the +24V source voltage.
