Delta Electronics AC Servo Drive ASDA-B User Manual
Page 313
Appendix A Accessories|ASDA-B Series
A-4
Revision February 2008, Doc. Name: 2006PDD23000009
Encoder Connectors
Delta Part Number: ASDBCAEN0000
Title
Part No.
Manufacturer
Housing AMP
(1-172161-9)
AMP
Terminal AMP
(170359-3)
AMP
CLAMP DELTA
(34703237XX)
DELTA
Delta Part Number: ASDBCAEN1000
Encoder Cables
Delta Part Number: ASDBCAEN0003/0005
Title
Part No.
Manufacturer
Housing AMP
(1-172161-9)
AMP
Terminal AMP
(170359-3)
AMP
CLAMP DELTA
(34703237XX)
DELTA
L
Title
Part No.
mm
inch
1 ASDBCAEN0003
3000
± 50
118
± 2
2 ASDBCAEN0005
5000
± 50
197
± 2
