Chapter 3 Connections and Wiring|ASDA-B Series
3-26 Revision February 2008, Doc. Name: 2006PDD23000009
2) When using RS-232 communication, the user can use the communication cable provided by Delta
PLC directly. (The PLC communication cable is compatible with all Delta Servo systems for the
users’ convenience)
3.5.2 Connection between PC/Keypad and Connector CN3
„ Connection between PC and CN3
2
3
5
5
4
8
PC or
Notebook
1 2
3
4
5
6
7
8
CN3 Drive Connector
„ Connection between Keypad and CN3
5
8
2
3
8
2
5
4
KEYPAD
1 2
3
4
5
6
7
8
1
3
5
7
9 2
4
6
8
10
CN3 Drive Connector
