Function Purpose
BESTlogic
Expression
Mode Setting
381 Overfrequency Protection Level 2 0 1
(Phase VT input)
481 Overfrequency Protection Level 1 0 1
(Phase VT input)
581 Overfrequency Protection Level 2 0 1
(Phase VT input)
GROUP Input 0 Logic: No manual selection logic is used 0 1
(discrete input
selection)
Input 1 Logic: No manual selection logic is used 0
Auto/Manual Logic: Set to 1 (/0) to enable automatic
selection. Manual selection is not used. /0
Table 8-13. 700V-OUVF-A-BE (Over/Under V & F Protection) Virtual Switch Logic
Switch Purpose Mode Label
State Labels
Closed Open
43 Not used 0 (disabled) SWITCH_43 Closed Open
143 Not used 0 (disabled) SWITCH_143 Closed Open
101 Not used 0 (disabled) N/A N/A N/A
Table 8-14. 700V-OUVF-A-BE (Over/Under V & F Protection) Virtual Output Logic
Output Purpose Description Label
State Labels
Closed Open
VOA
(OUTA) Relay Trouble alarm, Alarm
Major, Alarm Minor OUTA contact closes when
Relay Trouble, Major or
Minor alarm is TRUE RELAY_TR Active Normal
BESTlogic expression: VOA= ALMMAJ+ALMMIN
VO1
(OUT1) Not used VO1 True False
BESTlogic expression: VO1=0
VO2
(OUT2) Breaker Trip Contact
initiated by Voltage and
Frequency Trips OUT2 contact closes if any
voltage (24, 27P, 127P,
27X, 47, 59P, 159P, 59X,
159X) or frequency
(81
Y581) trip is TRUE.
V&F_BKR_TR Trip Normal
9376700990 Rev M BE1-700 Application 8-21
