Table 7-30, Coretemp sensor, Control via ipmi – Artesyn CPCI-6200 Installation and Use (May 2015) User Manual
Page 174
Control via IPMI
CPCI-6200 Installation and Use (6806800J66E)
174
Event Message Control
0x00
Per Threshold / Discrete State
Reading Definition
Analog reading byte
Analog sensor reading
Table 7-30 CoreTemp Sensor
Feature
Raw Value
Description
Sensor Name
CoreTemp
-
Sensor LUN
0x00
-
Sensor Number
0x0A
Entity ID
0x03
Sensor Type
0x01
Temperature
Event/Reading Type
0x01
Threshold
Assertion Event Mask (Byte 15)
0x95
-
Assertion Event Mask (Byte 16)
0x7A
-
Deassertion Event Mask (Byte 17)
0x95
-
Deassertion Event Mask (Byte 18)
0x7A
Threshold Mask (Byte 19)
0x3F
Threshold Mask (Byte 20)
0x3F
Base Unit
0x01
deg. C
Normal Reading
0xAA
42
Upper non-recoverable threshold
0xEE
110
Upper critical threshold
0xE4
100
Upper non-critical threshold
0xDA
90
Lower non-recoverable threshold
0x76
-10
Lower critical threshold
0x79
-7
Lower non-critical threshold
0x7B
-5
Rearm mode
0x01
Auto
Hysteresis Support
0x03
Readable and Setable
Table 7-29 Max1617Temp Sensor (continued)
Feature
Raw Value
Description
