DS4830A User’s Guide
35
4.2 – Module 1 Peripheral Registers
MODULE 1
Register index 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
I2CBUF_M 00h D[15:0]
I2CST_M 01h I2CBUS I2CBUSY - I2CAMI2 I2CSPI I2CSCL I2CROI I2CGCI I2CNACKI - I2CAMI I2CTOI I2CSTRI I2CRXI I2CTXI I2CSRI
I2CIE_M 02h - - - - I2CSPIE I2CAMI2E I2CROIE I2CGCIE I2CNACKIE - I2CAMIE I2CTOIE I2CSTRIE I2CRXIE I2CTXIE I2CSRIE
PO6 03h - PO6[6:0]
CRC8IN 04h CRC8IN[7:0]
MIIR1 05h - - - - - - - I2CM SVM P6_6 P6_5 P6_4 P6_3 P6_2 P6_1 P6_0
EIF6 06h - IFP6[6:0]
EIE6 07h - IEP6[6:0]
PI6 08h - PI6[6:0]
SVM 09h - - - - SVMTH[3:0] - - - - SVMI SVMIE SVMRDY SVMEN
I2CCN_M 0Ch - - - I2CM_ALT ADD2EN SMB_MOD I2CSTREN I2CGCEN I2CSTOP I2CSTART I2CACK I2CSTRS - - I2CMST I2CEN
I2CCK_M 0Dh I2CCKH[7:0] I2CCKL[7:0]
I2CTO_M 0Eh I2CTO[7:0]
I2CSLA_M 0Fh SLAVE_ADDRESS[7:1] I2CMODE
EIES6 10h - IESP6[6:0]
PD6 11h - PD6[6:0]
CRC8OUT 15h - CRC8OUT[7:0]
ADCG1 17h ADC VOLTAGE SCALE TRIM FOR GAIN1[13:0] - -
ADCG2 18h ADC VOLTAGE SCALE TRIM FOR GAIN2[13:0] - -
ADVOFF 19h ADC VOLTAGE OFFSET [15:0]
ADCG3 1Bh ADC VOLTAGE SCALE TRIM FOR GAIN3[13:0] - -
ADCG4 1Ch ADC VOLTAGE SCALE TRIM FOR GAIN4[13:0] - -
CHIPREV 1Dh CHIPREV[15:0]
I2CSLA2_M 1Eh SLAVE_ADDRESS[7:1] I2CMODE
