Appendices
2-189
1
Appendices
Jump and search Edit ➔ Jump in Ladder Monitor 2-105
➔ Search in Ladder Monitor 2-106
➔ Search for Device at Cursor Position in Ladder Monitor 2-107
Searches for instruction words and operands, or jumps to a specified line.
Monitor all
Displaying a monitor all window File ➔ Monitor All 2-109
Displays devices, current values, preset values, contacts, coils and
comments.
In this window, the ON/OFF status of bit devices can be changed,
and the attribute (bit count, radix and comment type) can be changed
using the dialog bar.
Registering devices 2-113
Devices to be displayed on the monitor all window can be registered
by dragging and dropping them from a ladder diagram or by using the
dialog bar.
Changing current values/preset values for devices 2-118
Using the dialog bar, current values can be specified and written to
devices. Currently saved values/preset values can be changed.
Resetting devices
Edit ➔ Reset Device in Monitor All/Registration Monitor 2-118
Returns the currently selected device to the default value.
Registration monitor
Displaying a registration monitor window File ➔ Registration Monitor 2-119
Displays current values, comments and timing charts for the regis-
tered devices. In this window, the ON/OFF status of bit devices can be
changed, and the attribute (bit count, radix and comment type) can be
changed using the dialog bar.
Registering devices 2-122
Devices to be displayed on the registration monitor window can be
registered by dragging and dropping them from a ladder diagram or by
using the dialog bar.
Setting the number of scales for timing charts
Settings ➔ Set No. of Scales for Timing Chart 2-129
Allows you to set the number of scans/steps (= number of scales) to
be displayed on timing charts.
Copying and deleting the device attribute
Edit ➔ Copy Device Attribute in Registration Monitor 2-125
➔ Delete Device in Registration Monitor 2-127
Copies the attribute (bit count, radix and comment type) set for the
currently selected device to another device, or deletes the device.
Sorting devices Edit ➔ Sort Devices in Registration Monitor 2-127
Sorts (arranges) devices in order.
Resetting devices Edit ➔ Reset Device in Monitor All/Registration Monitor 2-127
Returns the selected devices to their default values.
Timing chart 2-128
Timing charts for the registered devices are displayed while scans or
steps are executed (only when "Comment" on the dialog bar is set to
"No").
Mnemonic list window
When steps are executed, a mnemonic list window is displayed to 2-101
indicate the mnemonic line currently being executed.
Changing the current value/preset value/attribute (dialog bar)
Change device types, device numbers, current values, preset values, 2-96
etc. using the dialog bar, or register new devices to each monitor.
Set the bit count, radix and comment display method.
