Chapter 3 Simulator
2-124
3
Turning on/off the bit device
To turn on/off a bit device, perform the following procedure.
■ Turning on/off a bit device using the mouse
Place the cursor over the device to be turned on/off, and double-click it.
• The ON/OFF indication is toggled.
■ Turning on/off a bit device using the mouse
When the cursor color is the same as the title bar color, place the cursor in the
device to be turned on/off using the UP and DOWN keys, and press the space bar.
• The ON/OFF indication is toggled.
Changing the current value/preset value/attribute
The dialog bar allows you to change the type, number, attribute, current value and
preset value of devices.
➮ The procedure for changing these items is the same as that described for the monitor all. Refer to
"Changing the current value/preset value/attribute" on page 2-118.
Note: Even if bit devices are turned on/off or the current/preset values are changed
while operation is stopped, these settings are reset when an operation is started up.
Pause the operation, and then change the device status.
ON status OFF status
7015 – – B01
7100 B01
7101 – – B01
7015 – – B01
7100 – – B01
7101 – – B01
