Appendices
Relay No. Function
2206 Selects edge of INT3. 0: Rising edge 1: Falling edge
*2207 Reverses (toggles) output to 0501 by comparator 0501. 1: ON 0: OFF
*2208 Direct output to 0501. 1: Disabled 0: Enabled
*2209 Turns OFF output to 0501. 1: Yes 0: No
*2210 Turns ON output to 0501. 1: Yes 0: No
*2211 Reverses (toggles) output to 0501. 1: Yes 0: No
*2212 When comparator CTC3 is ON, clears CTC1 automatically. 1: Yes 0: No
*2213 Uses CTH1 in multiply mode. 1: Yes 0: No
*2214 Selects multiply mode for CTH1. 1: x4 0: x2
*2215 Enables external reset of CTH1. 1: Yes 0: No
Relay No. Function
*2300 Disables output to all relays (500 to 515, 7000 to 17915). 1: Yes 0: No
*2301 Disables input to all relays. 1: Yes 0: No
*2302 Stops execution of user program (Does not stop interrupts.). 1: Stop 0: Run
*2304 Constant scan time mode (preset value in TM29). 1: Valid 2: Invalid
*2305 Remains ON only for first scan when constant scan time is exceeded.
Forced reset (Initializes DM/TM/TMR/C utility relays by MEMSW except
high-speed counters.).
1: Yes 0: No
*2306 Turns ON when remote is disconnected, and is cleared when operation is
started. (Refer to DM9500 to DM9517.)
*2308 Stops X-axis motor driver.
*2309 Remains ON while X-axis motor driver is operating or in emergency stop
status.
*2310 Starts operation of X-axis motor driver (by detecting rising edge).
*2311 Stops Y-axis motor driver.
*2312 Remains ON while Y-axis motor driver is operating or in emergency stop
status.
*2313 Starts operation of Y-axis motor driver (by detecting rising edge).
*2314 Converts ASCII character string into BIN (32 bits) (by detecting rising edge).
*2315 Converts BIN (32 bits) into ASCII character string (by detecting rising edge).
2600 to 2608 Used to convert extended ladder into standard ladder.
*2803 Sends break signal (during ON).
2804 Text data receive relay. Remains ON for one scan when text data is
received.
2805 Text data overflow. Remains ON for one scan when text data is not correctly
received.
2806 Text data communication error. Remains ON for one scan when a text data
communication error occurs.
*2807 Starts transmission of text data. Remains ON during transmission.
*2812 Power supply error
*2813 Sets input time constant for 0108 to 0215 (KV-80) to 25 µs. 1: Yes 0: No
Sets input time constant for 0000 to 0009 (KV-300) to 10 µs. 1: Yes 0: No
2814 Disables any other key input during HKEY instruction.
2815 Terminates scan in HKEY instruction.
2900 to 2915 Stores key information on HKEY instruction.
Level of
direct output
to 0501 by
comparator
CTC3
(either one
is ON)
* Valid with the KV-300 only.
