Chapter 3 Simulator
2-121
1
3
2. Select "Save Window As" from the "File" menu, or click the
button.
•
The "Save Window As" dialog box is displayed.
3 Specify the folder (directory) and the file name in which the file is to be saved.
Reading the registration monitor file
File
➔ Open Window
To read a registration monitor file, perform the following procedure.
1. Select "Open Window" from the "File" menu.
•
The "Open Window" dialog box is displayed.
2. Specify the folder and file name in which the file to be read is located.
3. Click the [OK] button.
•
The specified file is read, and the registration monitor window is opened.
Folder (directory)
Select the folder (directory) in which the file is to be saved.
The current folder (directory) is selected as the default.
File Name
Enter the file name using up to 8 letters and numbers.
The extension is set to "kre", and should not be changed.
Folder (directory)
Select the folder (directory) in which the file to be read is saved.
The current folder (directory) is selected as the default.
File Name
Specify the file name to be read. The extension is set to "kre".
File Type
Select the type of the file to be read.
"Registration Monitor (*.kre)" and "Monitor All (*.kal)" are available.
