doepfer System A - 100 VC Slew Limiter A-171
5
Slew Limiter as VC AR generator
You can also use the A-171 as a simple AR genera-
tor, for instance with the percussive sound in the
example in Fig. 3. The attack/release parameters can
be controlled by MIDI, for instance by the voltage at
the CV2 output on the A-190. MIDI
A-171
VCO
gliss. gliss.
CV 1
MIDI In
A-190
CV 2
CV 1/2
MIDI
VCO VCF
A-171
ADSR
VCA
CV 1
MIDI In
A-190
CV 2
Gate
CV 1/2
Fig. 2: A-171 as real-time
controlled portamento generator.
Fig. 3: A-171 as
VC AR Generator.
