doepfer System A - 100 Sampler A-112
5
5 Switch • 6 Switch • 7 Switch
With the 3-position switches 4 to 6 the operating
mode is selected. The table on the left lists all possible
modes. The modes are described in the following
paragraphs.
In particular the gate signal (gate input § / manual
trigger 4) controls different functions in the respective
operating modes.
H Please note that in some modes it is not
sufficient to change the switches position to
exit the mode. In the following description of
the modes you will find detailed information
on how to exit a selected mode.
5 5 5 5 6 6 6 6 7 7 7 7 Function
Loop not implemented
Dmp Norm Dump a sample
Wav Dump a wave
Loop Play a loop
S1, S2 Play Norm Play a sample
Wav Play a wave
Loop Record a loop
Rec Norm Record a sample
Wav Record a wave
Len Input sample length required
Pit Norm Pitch Shift
Frz. Pitch Shift with "Freeze"
Len Input sample length required
Eff Del Norm Delay
Frz. Delay with "Freeze"
Len Input sample length required
Rev Norm Reverse Delay
Frz. Reverse Delay with "Freeze"
