2-830
Cisco Catalyst Blade Switch 3120 for HP Command Reference
OL-12248-03
Chapter 2 Cisco Catalyst Blade Switch 3120 for HP Cisco IOS Commands
vlan (VLAN configuration)
media {ethernet | fddi |
fd-net | tokenring | tr-net}
(Optional) Specify the VLAN media type.
lists the valid
syntax for each media type.
•
ethernet is Ethernet media type (the default).
•
fddi is FDDI media type.
•
fd-net is FDDI network entity title (NET) media type.
•
tokenring is Token Ring media type if the VTP v2 mode is
disabled, or TrCRF if the VTP v2 mode is enabled.
•
tr-net is Token Ring network entity title (NET) media type if the
VTP v2 mode is disabled or TrBRF media type if the VTP v2 mode
is enabled.
mtu mtu-size
(Optional) Specify the maximum transmission unit (MTU) (packet size
in bytes). The range is 1500 to 18190.
name vlan-name
(Optional) Specify the VLAN name, an ASCII string from 1 to 32
characters that must be unique within the administrative domain.
parent parent-vlan-id
(Optional) Specify the parent VLAN of an existing FDDI, Token Ring,
or TrCRF VLAN. This parameter identifies the TrBRF to which a
TrCRF belongs and is required when defining a TrCRF. The range is 0
to 1005.
ring ring-number
(Optional) Specify the logical ring for an FDDI, Token Ring, or TrCRF
VLAN. The range is 1 to 4095.
said said-value
(Optional) Enter the security association identifier (SAID) as
documented in IEEE 802.10. The range is 1 to 4294967294, and the
number must be unique within the administrative domain.
state {suspend | active}
(Optional) Specify the VLAN state:
•
If active, the VLAN is operational.
•
If suspend, the VLAN is suspended. Suspended VLANs do not
pass packets.
ste ste-number
(Optional) Specify the maximum number of spanning-tree explorer
(STE) hops. This keyword applies only to TrCRF VLANs. The range
is 0 to 13.
stp type {ieee | ibm | auto}
(Optional) Specify the spanning-tree type for FDDI-NET, Token
Ring-NET, or TrBRF VLAN.
•
ieee for IEEE Ethernet STP running source-route transparent
(SRT) bridging.
•
ibm for IBM STP running source-route bridging (SRB).
•
auto for STP running a combination of source-route transparent
bridging (IEEE) and source-route bridging (IBM).
tb-vlan1 tb-vlan1-id
and tb-vlan2 tb-vlan2-id
(Optional) Specify the first and second VLAN to which this VLAN is
translationally bridged. Translational VLANs translate FDDI or Token
Ring to Ethernet, for example. The range is 0 to 1005. Zero is assumed
if no value is specified.
