3-10
Operator Interface
7000L-UM300I-EN-P – June 2013
7000 “C” Frame
b) Obtaining Drive Database - During this phase, the database of
information about the drive is obtained from the drive.
Obtaining the database at this point in time is optional and may
be aborted by pressing any key on the operator interface.
Obtaining the entire database does however speed up subsequent
operations since relevant portions of the database do not have to
be obtained. (Without obtaining the entire database, the
operator interface will access portions of the drive database as
required. This slows down the first access to the operation that
requires the data. Subsequent operations requiring the same data
are not affected). Aborting the download will not affect portions
of the database already obtained.
Once the database has been obtained, the
operator interface will
start
up in one of two modes, depending on to what degree the drive has
previously been configured:
a)
On an unconfigured drive, the
operator interface will
enter the
'
Setup
Wizard' mode. Until the user has gone through the entire
'
Setup
Wizard', this will be the default mode to power up in.
The '
Setup Wizard
' can be cancelled at any time by pressing the
appropriate
Softkey
.
b)
Once the drive has been configured through the '
Setup Wizard
',
the Top Level Menu, will be displayed from this point forward.
The '
Setup Wizard
' can be re-entered via the Setup Menu.
