Configuration
7-8
48XX/49XXSHB0399
Enable of additional acceleration and deceleration times
With terminal control, the inputs must be assigned according to the table below
to enable the additional acceleration and deceleration times. T
i
times can only be
activated in pairs.
input
2. input
3. input
4. input
T
ir1
, T
if1
1
0
0
0
T
ir2
, T
if2
0
1
0
0
T
ir3
, T
if3
1
1
0
0
T
ir4
, T
if4
0
0
1
0
T
ir5
, T
if5
1
0
1
0
T
ir6
, T
if6
0
1
1
0
T
ir7
, T
if7
1
1
1
0
T
ir8
, T
if8
0
0
0
1
T
ir9
, T
if9
1
0
0
1
T
ir10
,T
if10
0
1
0
1
T
ir11
,T
if11
1
1
0
1
T
ir12
,T
if12
0
0
1
1
T
ir13
,T
if13
1
0
1
1
T
ir14
,T
if14
0
1
1
1
T
ir15
,T
if15
1
1
1
1
The input with the lowest figure is the first input, the input with the next higher figure
is the second input, and so on (e. g. E4 = 1. input, E5 = 2. input).
C130 displays the momentarily active T
i
times.
With control via keypad or LECOM interfaces, C130 is used for the activation of
the T
i
times in pairs.
Code
Name
Possible settings
Lenze Selection
Info
C130*
¤ Enable of
additional
T
i
times
0
-0-
T
ir
(C012) / T
if
(C013) active
-1-
T
ir1
/ T
if1
active
...
-15-
T
ir15
/ T
if15
active
If the T
i
times are enabled via terminal,
C130 is for display only.
