The operating state of the controller is indicated under C068. angezeigt.
Bit No. 15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Signal TRIP
I
max
QSP IMP Run n
act
= 0 Ctrl.
enab
le
Communication error
Operation error
( Display of the operating state of the controller.
The operating state of the controller is displayed under C069.
Bit No.
7
6
5
4
3
2
1
0
Signal
Ctrl.
enable
xxx
RESET
AUTO
REMOT
PCHG
CALARM
BALARM
Meaning Controller
enable
Controller
reset
Terminal
control
LECOM
control
Operating
mode changed
Communicatio
n error
Operation
error
( LECOM1 baud rate
The baud rate can be set under C125.
Code
Name
Possible settings
Code
Name
Lenze Selection
Info
C125*
¤ Baud rate
changeover
for
interface
0
-0-
9600 baud
-1-
4800 baud
-2-
2400 baud
-3-
1200 baud
Note!
For communication via modem please contact Lenze.
( History of the reset fault
Codes C161 to C168 indicate the last 8 TRIPs stored. The fault reset last is
indicated under C161.
( LECOM1 code bank
With version 1.0 of the LECOM-A/B protocol only codes up to C255 can be
processed. The access range of this version can be changed under C249 so that
it is possible to reach higher codes. Code C249 does not exist in every code range.
Parameter in C249
Access to code range
0
C000...C255
1
C250...C505
2
C500...C755
3
C750...C1005
4
C1000...C1255
5
C1250...C1505
6
C1500...C1755
7
C1750...C2000
For more information about serial communication with the standard interface
LECOM1 (LECOM-A/B) see the Operating Instructions LECOM-A/B.
