Automation

13-7

48XX/49XXSHB0399

13.2

Mains chokes

The following mains chokes are for operation with mains voltages up to

#550V

+ 0%.

13.2.1

Mains chokes for power connection

Type

Rated data

Order designation

L

I

P

loss

1)

[W]

m [kg]

4902

3

ô 1.2 mH

3

ô 17 A

30

3

ELN3-0120H017

4903

3

ô 1.1 mH

3

ô 25 A

46

6

ELN3-0120H025

4904

3

ô 0.75 mH

3

ô 45 A

80

10

ELN3-0075H045

4905

3

ô 0.27 mH

3

ô 105 A

120

20

ELN3-0027H105

4906

3

ô 165 mH

3

ô 170 A

125

32

ELN3-0017H170

4907

3

ô115 mH

3

ô 270 A

215

40

ELN3-0011H270

4X08

3

ô 94 mH

3

ô 300 A

220

50

ELN3-0009H300

4X09

3

ô 60 mH

3

ô 450 A

245

58

ELN3-0006H450

4X11

3

ô 46 mH

3

ô 600 A

280

77

ELN3-0005H600

4X12

3

ô 32 mH

3

ô 900 A

390

125

ELN3-0003H900

4X13

3

ô 28 mH

3

ô 1000 A

360

115

ELN3-0003H1k0

1) for operation with rated current

f

m

c
a

d
b

n

e

k

K35.0094

FIG 13-5

Mains chokes with connection lug
