Configuration
7-140
48XX/49XXSHB0399
Code
Possible settings
Name
Code
Info
Selection
Lenze
Name
C320*
V
p2
of the n-
controller
adaption
8
1
{1}
1000
Second gain factor for speed controller
adaption
C321*
V
p3
of the n-
controller
adaption
8
1
{1}
1000
Third gain factor for speed controller
adaption
C322*
n
1
of the n-
controller
adaption
3000
rpm
0 rpm
{1 rpm}
5000 rpm
Speed setpoint threshold of speed
controller adaption, condition: n
1
> n
0
C323*
n
0
of the n-
controller
adaption
50 rpm 0 rpm
{1 rpm}
5000 rpm
Speed setpoint threshold of speed
controller adaption, condition: n
1
> n
0
C324*
¤ n-controller
adaption on/off
0
-0-
n-controller adaption is off
-1-
n-controller adaption is on
C325*
V
p2
of the
process
controller
adaption
1
0.1
{0.1}
10
10
{1}
500
Second gain factor for process controller
adaption
C326*
V
p3
of the
process
controller
adaption
1
0.1
{0.1}
10
10
{1}
500
Third gain factor for process controller
adaption
C327*
set2 of the
process
controller
adaption
100 % 0.0 %
{0.1 %}
100.0 %
Setpoint speed threshold of the process
controller adaption, condition: set2 > set1
C328*
set1 of the
process
controller
adaption
0%
0.0 %
{0.1 %}
100.0 %
Setpoint speed threshold of the process
controller adaption, condition: set2 > set1
C329*
¤ Process
controller
adaption on/off
0
-0-
Process controller adaption is off
-1-
Process controller adaption is on
C330*
Setpoint of the
process
controller
0%
-100.0 %
{0.1 %}
100.0 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C331*
Evaluation of
the process ctrl.
output
100 % -100.0 %
{0.1%}
100.0 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C332*
Acceleration
time T
ir
of the
process
controller
setpoint
0.00 s 0.00 s
{0.01 s}
1.00 s
1.0 s
{0.1 s}
10.0 s
10 s
{1 s}
100 s
100 s
{10 s}
990 s
C333*
Deceleration
time T
if
of the
process ctrl.
setpoint
0.00 s 0.00 s
{0.01 s}
1.00 s
1.0 s
{0.1 s}
10.0 s
10 s
{1 s}
100 s
100 s
{10 s}
990 s
C334*
Acceleration
time T
ir
of the
process ctrl.
evaluation
0.00 s 0.00 s
{0.01 s}
1.00 s
1.0 s
{0.1 s}
10.0 s
10 s
{1 s}
100 s
100 s
{10 s}
990 s
C335*
Deceleration
time T
if
of the
process ctrl.
evaluation
0.00 s 0.00 s
{0.01 s}
1.00 s
1.0 s
{0.1 s}
10.0 s
10 s
{1 s}
100 s
100 s
{10 s}
990 s
