Preface and general information
1-8 48XX/49XXSHB0399
Generic standards considered for the test of noise emission:
Basic standard Test Limit value
EN 61000-4-2 3/95 Electrostatic discharge on housing and heatsink Severity 3
6kV for contact,
8kV clearance
IEC 1000-4-3 2/95 Electromagnetic fields
Frequency range 26-1000MHz
Severity 3
10V/m
ENV 50140 8/93 High-frequency field
Frequency range 80-1000MHz,
80% amplitude modulated
Severity 3
10V/m
Fixed frequency
900MHz with 200Hz, 100 % modulated 10V/m
EN 61000-4-4 3/95 Fast transients,
burst on power terminals
Severity 3
2kV/5kHz
Burst on bus and control cables Severity 4
2kV/5kHz
EN 61000-4-5 10/94 Surge test
Mains cable
Installation class 3
Hameln, 01/03/1999
(i. V. Schäfer) (i. A. Tolksdorf)
Product Manager Commissioned for CE
