Commissioning
5-2 48XX/49XXSHB0399
Wiring recommendation for speed control with tacho
Z1
K1
F’1...F’3
L K
F’’1...F’’3
Q1
L1
L2
L3
PE
L1 L2 L3
L’1 L’2 L’3
L1 L2 L3 PE
I K 20 B
F’4
M
I K A B
M1
21 28 3940 59 90FE 8 9 7
X1 X2 X3 X4
4900
A
Ctrl.
enable
CW
nset
T
4 3 5 22
CCW
K2
A4
K3
QSP nact = 0
S1
S2 K2
K2 K2.1 K1
K2.1
K2 K3
K1
td
td > tbr.
L11
L10
L20
4900Str024
FIG 5-1 Flow chart section: Speed control with tacho
F’’1...F’’3 Cable protection fuse L11 ”Emergency stop” cable
F’1...F’3 Semiconductor fuse LK Mains choke
F’4 Armature fuse M1 Motor
K1 Mains contactor nset Setpoint potentiometer
K2 QSP relay CW CW rotation
K2.1 Delay timer Ctrl. enable Controller enable
K3 Motor standstill Q1 Main switch
CCW CCW rotation QSP Quick stop function
L10 Direct cable from the control cable ”ON” Z1 RFI filter
With a tacho voltage to ground: bridge terminals X1/4 and X1/5 and configure the
switch S4 on the control module for the operation with a tacho signal to ground
(chpt. 4.3.4.1).
