Configuration
7-43
48XX/49XXSHB0399
4900Str042
X 7
X 5
X 8
X 1
X 9
S W I
R
X 7
X 5
X 8
X 9
R
X 7
X 5
X 8
X 9
R
j
, n - c t r l .
E n c o d e r
o u t p u t
R e s o l v e r
I n c r e m e n t a l
e n c o d e r
M a s t e r d r i v e w i t h
m a s t e r i n t e g r a t o r
F a c t o r
j
, n - c t r l .
E n c o d e r
o u t p u t
R e s o l v e r
I n c r e m e n t a l
e n c o d e r
S l a v e 1
F a c t o r
j
, n - c t r l .
E n c o d e r
o u t p u t
R e s o l v e r
I n c r e m e n t a l
e n c o d e r
S l a v e 2
FIG 7-15
Connection diagram for the configuration of the digital frequency bar
M
Master drive with master integrator
S1
Slave 1
S2
Slave 2
R
Resolver
Features
( Either resolver or incremental encoder feedback
( Hardware connection between DF output and DF input
( Another evaluation of the set-value with a factor (numerator/denominator)
for the corresponding slave (gearbox adaptation). Adjustable via LECOM,
motor potentiometer or analog terminal
( External torque limitation possible
( QSP function for the individual drive. The DF set-value will be output
independently of QSP.
( RFR function for the individual drive. The set-value will be output to the DF
output independtly of the QSP.
( Influence possible via codes for phase trimming and speed correction (via
LECOM, motor potentiometer, analog terminal or one of the signal sources
under C145)
( Following error limit adjustabel via code
( TRIP when reaching the phase controller limit
( Speed limit = 1.8 ¼ C011
( Phase controller influence of 0 (0 = deactivated) adjustable up to 1.00
( No alternative set-value conditioning available
(JOG, additional set-value, set-value integrator...)
