C2356 Time settings for XCAN
(AIF interface X1)
1 XCAN times 0 0 {1 ms} 65000 XCAN boot−up time:
Delay time after mains
connection for initialisation
through the master.
2 XCAN times 0 XCAN1...3_OUT cycle times:
Factor for the task time to send
process data object.
0 = event−controlled
transmission
3 XCAN times 0
4 XCAN times 0
5 XCAN times 0 Delay time for initial
transmission of the process data
objects after the NMT status
changed to "Operational"
C2357 Monitoring time for XCAN
process data input objects
(AIF interface X1)
Only ECSxA: When the subcodes
1 ... 4 are set, consider the task
runtime:
C2357/1...4 = Desired monitoring
time / task runtime
1 CE monit time 3000 1 {1 ms} 65000 XCAN1_IN monitoring time
2 CE monit time 3000 XCAN2_IN monitoring time
3 CE monit time 3000 XCAN3_IN monitoring time
4 CE monit time 3000 Bus−off
5 CE monit time 3000 AIF monitoring time (can only be
set if C2357/6 = 0)
6 CE monit time 0 Sync monitoring time (can only
be set if C2357/5 = 0)
C2359 AIF HW Set. 0
0 {1} 65535
C2367 Sync Rx Id 128 XCAN receive identifier of the
sync telegram(AIF interface X1)
1 {1} 2047
C2368 Sync Tx Id 128 XCAN send identifier of the sync
telegram
(AIF interface X1)
1 {1} 2047
C2373 XCAN Sync counter
(AIF interface X1)
1 Sync Rate IN 1 1 {1} 240 XCAN1_IN
2 Sync Rate IN 1 XCAN2_IN
3 Sync Rate IN 1 XCAN3_IN
C2374 XCAN Sync counter
(AIF interface X1)
1 Sync Rate OUT 1 1 {1} 240 XCAN1_OUT
2 Sync Rate OUT 1 XCAN2_OUT
3 Sync Rate OUT 1 XCAN3_OUT
