Appendix
Code table
l
283
EDBCSXM064 EN 11.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0061 Heatsink
temp
Heatsink temperature
Read only
^ 231
−200
{1
°C}
200
C0062 Interior temp
Interior device temperature
Read only
^ 232
−200
{1
°C}
200
C0063 Mot temp
Motor temperature
Read only
^ 229
0
{1
°C}
200
C0064 Utilization
Device utilisation (I x t) over the
last 180 s
Only display
0
{1 %}
150
l
C0064 > 100 % activates
OC5−TRIP.
l
TRIP−RESET only is possible if
C0064 < 95 %.
C0065 U24 ext
External low−voltage supply
(U
24
)
Read only
0,0
{0.1V}
100,0
C0066 Motor load
Thermal motor load I
2x
t
Only display
^ 237
0
{1 %}
250
C0067 Act trip
Current fault (TRIP)
(in case of FAIL−QSP, warning and
message, "0" is displayed.)
Only display
^ 270
C0070 Vp speedCTRL
3.0
Proportional gain of speed
controller (V
pn
)
^ 183
0.00
{ 0.01}
127.99
C0071 Tn speedCTRL
24.0
Reset time − speed controller
(T
nn
)
^ 183
1.0
{0.5 ms}
6000.0
C0072 Td speedCTRL
0.0
Derivative gain of speed
controller (T
dn
)
^ 183
0.0
{0.1 ms}
32.0
C0074 Dynamics
0
{1}
Feedforward control of the
current controllers for a higher
dynamic performance
^ 178
0
Normal
1
Enhanced
C0075 Vp currCTRL
20.0
Proportional gain of current
controller (V
pi
)
The upper limit is
device−dependent.
^ 178
0.00
{0.01
W}
381.80 ECSxS/P/M/A004
190.90 ECSxS/P/M/A008
95.46 ECSxS/P/M/A016
47.72 ECSxS/P/M/A032
31.82 ECSxS/P/M/A048
23.86 ECSxS/P/M/A064
