Code table
12
l
304 EDBCSXM064 EN 11.0
IMPORTANT Possible settings Code
Selection Lenze/
{Appl.} Designation No.
7 User menu 168.01 C0183 Fail number Display of current fault message
8 User menu 0.00 Not assigned
9 User menu 22.00 C0022 Imax current Input of maximum output
current
10 User menu 0.00 Not assigned
11 User menu 11.00 C0011 Nmax Input of the maximum speed
12 User menu 0.00 Not assigned
13 User menu 0.00 Not assigned
14 User menu 105.00 C0105 QSP Tif Input of quick stop deceleration
time
15 User menu 0.00 Not assigned
16 User menu 70.00 C0070 Vp speed CTRL Input of speed controller gain
(Vp)
17 User menu 71.00 C0071 Tn speed CTRL Input of speed controller reset
time (Tn)
18 User menu 0.00 Not assigned
19 User menu 2100.00 C2100 Time slice Input of time dial for cycl. task
20 User menu 2102.00 C2102 Task switch Selection of the switching
function for cycl. task
21 User menu 2104.00 C2104 PLC autorun Autom. start of the PLC program
after mains power−up
22 User menu 2106.00 C2106 Download protect Write protection of the PLC
program
23 User menu 2108.00 C2108 PLC run/stop Control of the PLC program
24 User menu 2111.00 C2111 GDC ID Creation date of the PLC program
25 User menu 2113.00 C2113 PLC prog name Name of the PLC program
26 User menu 2115.00 C2115 T−fct Credit Number of technology units
27 User menu 0.00 Not assigned
28 User menu 0.00 Not assigned
29 User menu 0.00 Not assigned
30 User menu 0.00 Not assigned
31 User menu 94.00 C0094 Password Parameter access protection for
the keypad
32 User menu 3.00 C0003 Par save Save parameter set
[C0540] X8 Signal out 2 Function of the digital frequency
output signals at X8 (DFOUT) ^ 109
0 No function
1 No function
2 Encoder simulation + zero pulse ®
DFOUT
C0545 PH offset 0 Phase offset
0 {1 inc} 65535 1 revolution = 65535 increments
C0547 DIS: AN−IN Analog signal on the input of the
DFOUT block
Read only
−199.99 {0.00 %} 199.99
C0549 DIS: DF−IN Speed on the input of the DFOUT
block
Only display
−32767 {1 rpm} 32767
