2.12 MCTRL_MotorControl (node number 131)
9300 Servo PLC
System blocks
2−72
L
9300 Servo PLC EN 5.1
Overview of system error messages of the motor control
Error Monitoring function System variable Possible responses
· Lenze setting ü Setting possible
No. Display Code TRIP Message Warning FAIL−QSP Off
x011 OC1 Short circuit MCTRL_bShortCircuit_b ·
x012 OC2 Earth fault MCTRL_bEarthFault_b ·
x015 OC5 I x t overload MCTRL_bIxtOverload_b ·
x016 OC6 I 2 x t overload MCTRL_bI2xtMotorloadOc6_b ·
x018 OC8 I 2 x t overload MCTRL_bI2xtMotorloadOc8_b C0606 ь · ь
x020 OU Overvoltage MCTRL_bOvervoltage_b ·
x030 LU Undervoltage MCTRL_bUndervoltage_b ·
x032 LP1 Motor phase failure MCTRL_bMotorphaseFail_b C0597 ь ь ·
x050 OH Heatsink temperature (fixed) MCTRL_bKuehlGreaterSet−
Value_b ·
x053 OH3 Motor temperature (fixed) MCTRL_bMotorTempGreater−
SetValue_b C0583 · ü
x054 OH4 Heatsink temperature
(adjustable) MCTRL_bKuehlGreaterC0122_b C0582 · ü
x057 OH7 Motor temperature (adjustable) MCTRL_bMotorTemp−
GreaterC0121_b C0584 · ü
x058 OH8 Motor temperature (PTC) MCTRL_bPtcOverTemp_b C0585 ь ь ·
x082 Sd2 Resolver error MCTRL_bResolverFault_b C0586 · ь ь
x086 Sd6 Thermal sensor error MCTRL_bSensorFault C0594 · ь ь
x087 Sd7 Absolute value encoder error 1) MCTRL_bEncoderFault_b ·
x088 Sd8 Absolute value encoder error 1) MCTRL_bSinCosFault_b C0580 ü ·
x089 PL Error during rotor position
adjustment MCTRL_bRotorPositionFault_b ·
x190 nErr Speed out of tolerance margin MCTRL_bSpeedLoopFault_b C0579 ь ь ь ь ·
x200 NMAX Maximum speed exceeded MCTRL_bNmaxFault_b ·
x: 0 = TRIP, 1 = Message, 2 = Warning, 3 = FAIL−QSP
1) When the error has been eliminated: Deenergise the controller completely!
