9300 Servo PLC
Appendix
3.5 System error messages
3−107
L
9300 Servo PLC EN 5.1
3.5.1 Overview of system error messages, error sources and reactions
System error message Possible settings/response
· Lenze setting ü setting possible Available in
No. Display Source Meaning Code TRIP Message Warning FAIL−QS
P
Off Drive
PLC
Servo
PLC
ECSxA
x011 OC1 MCTRL Motor cable short circuit · ь ь
x012 OC2 MCTRL Motor cable earth fault · ь ь
x015 OC5 MCTRL I x t overload · ь ь
x016 OC6 MCTRL I 2 x t overload (C0120) · ü
x017 OC7 MCTRL I x t warning (C0123) C0604 ь · ь ь
x018 OC8 MCTRL I 2 x t warning (C0127) C0605 ь · ь ь
x020 OU MCTRL Overvoltage in the DC bus · ь ь
x030 LU MCTRL Undervoltage in the DC bus · ь ь
x032 LP1 MCTRL Motor phase failure C0597 ь ь · ь ь
x050 OH MCTRL Heat sink temperature higher than fixed limit
temperature · ь ь
x051 OH1 MCTRL Temperature inside the controller > 90° C · ü
x053 OH3 MCTRL Motor temperature higher than fixed limit
temperature C0583 · ь ь ь
x054 OH4 MCTRL Heat sink temperature higher than variable
limit temperature (C0122) C0582 · ь ь ь
x055 OH5 MCTRL Temperature inside the controller > C0124 C0605 ь · ь ь
x057 OH7 MCTRL Motor temperature higher than variable limit
temperature (C0121) C0584 · ь ь ь
x058 OH8 MCTRL Motor temperature via inputs T1/T2 too high C0585 ь ь · ь ь
x061 CE0 AIF Communication error between AIF
module
óPLC
C0126 ь ь · ь ь ь
CAN communication error:
x062 CE1 CAN1 CAN1_IN (monitoring time can be set under
C0357/1) C0591
ь ь · ь ь ь
x063 CE2 CAN2 CAN2_IN (monitoring time can be set under
C0357/2) C0592
x064 CE3 CAN3 CAN3_IN (monitoring time can be set under
C0357/3) C0593
x065 CE4 CAN CAN BUS−OFF status
(too many faulty telegrams received) C0595 ь ь · ь ь ь
x066 CE5 CAN CAN time−out (gateway function C0370) C0603 ь ь · ь ь ь
x070 U15 internal Undervoltage of internal 15 V voltage supply · ь ь ь
x071 CCr internal Internal error 1) · ь ь ь
x072 PR1 internal Check sum error in parameter set 1
· ь ь ь
x074 PEr internal Program error 1)
· ь ь ь
x075 PR0 internal General error in the parameter sets 1)
· ь ь ь
x076 PR5 internal Error saving parameters
· ь ь
x079 PI internal Error during parameter initialisation 1) · ь ь ь
x080 PR6 internal Too many user codes · ь ь ь
x082 Sd2 MCTRL Resolver error C0586 · ь ь ь ь
x083 Sd3 MCTRL Encoder error at X9 PIN 8 C0587 ь ь · ь
x085 Sd5 MCTRL Encoder error at analog input (X6) (C0034 = 1) C0598 ь ь · ь ь
x086 Sd6 MCTRL Sensor error: motor temperature (X7 or X8) C0594 · ь ь ь ь
x087 Sd7 MCTRL Absolute−value encoder error at X8 1) C0025 · ь ь
x088 Sd8 MCTRL Absolute−value encoder error at X8 1) C0580 ь · ь ь
x: 0 = TRIP, 1 = Message, 2 = Warning, 3 = FAIL−QSP
1) After error correction: completely deenergise the device!
