9300 Servo PLC EN 5.1
3.6
Code table
How to read the code table:
Column
Abbreviation
Meaning
Code
C0168
1
2
…
8
Code C0168
Subcode 1 of code C0168
Subcode 2 of code C0168
…
Subcode 8 of code C0168
[C0156] Parameter value of code can only be changed when controller is inhibited.
LCD
Keypad LCD
Lenze
Lenze setting of the code
g
Display code (can only be displayed)
à
The "info" column contains more information.
Selection
1
{1 %}
99 Minimum value
{smallest step/unit}
maximum value
Informati
on
Additional information on code
Code
LCD
Possible settings
Information
Lenze
Selection
[C0002] Par load
0
Load parameter set
·
Only possible when PLC has been stopped.
·
Parameter set 1 is automatically loaded after
power−on.
0
Load Lenze setting into RAM
1
Load parameter set 1 into RAM
2
Lenze setting and codes−
Load initialisation values into RAM
C0003 Par save
0
Save parameter set
·
Also possible when PLC is in operation.
0
Saving completed
1
Non−volatile saving of parameter set 1
C0004 Op display
56
Keypad operating display
·
Keypad will indicate selected code in the operating
level if no other status indications of C0183 are active.
All available codes
[C0006] Op mode
à
Operating mode of the motor control
à
Dependent on C0086
·
If C0086 is changed, the value is reset to the assigned
Lenze setting.
·
Change of C0006 sets C0086 = 0.
·
ESC (Extended Speed Control):
Speed control with increased speed control steadiness
for operation with incremental encoder only (not
resolver!).
2
Servo async Y
Servo control for asynchronous motors in star connection
3
Servo PM−SM Y
Servo control for synchronous motors in star connection
22
Servo async
Servo control for asynchronous motors in delta connection
31
ASM Y − ESC
Servo control for asynchronous motors in star connection,
ESC
32
PM−SM Y − ESC
Servo control for synchronous motors in star connection,
ESC
33
ASM − ESC
Servo control for asynchronous motors in delta connection,
ESC
C0009 LECOM address
1
LECOM controller address
(bus device number for operation via interface)
·
10, 20, ..., 90 reserved for broadcast to device groups
for RS232, RS485, fibre optics.
1
{1}
99
