3.6 Code table
9300 Servo PLC
Appendix
3−146
L
9300 Servo PLC EN 5.1
Code Information Possible settings LCD Code Information
Selection Lenze
LCD
C1191 Char.: temp PTC: Temperature characteristic selection
0 {1 °C} 255
1 100 Characteristic for temperature 1
2 150 Characteristic for temperature 2
C1192 Char.: OHM PTC: Resistance characteristic selection
0 {1 W} 30000
1 1670 Characteristic for R1 at temperature 1
2 2225 Characteristic for R2 at temperature 2
C1799 DFOUT fmax 1250 DF_OUT_DigitalFrequency:
Maximum output frequency at X10
Note: The limitation of the maximum output frequency at
DfOut is faulty for operating systems <=7.5.
20 {1} 1250 1250 corresponds to 500 kHz
C1810 S/W Id keypad
g
Keypad identification
C1811 S/W date keypad g Keypad creation date
C2100 Time slice 13 Time slice for task switch between system task and cyclic
task (PLC_PRG)
6 {1 ms} 26
C2102 Task switch 0 Configuration of task switch process
Activation after:
0
Time slice
1 Time slice + end PLC_PRG
2 Time slice + end PLC_PRG + end system task
C2104 PLC Autorun 0 Automatic start of the PLC program after power switch−on
0 No auto start
1 Auto start after power−on
C2106 Downl.protect 0 Write protection for the PLC program
0 New download possible
1 No new download possible
C2107 PwDownlProt. 0 Password for download write protection (C2106)
0 {1} 4294967295
C2108 PLC run/stop 0 PLC program
0 No function
1 PLC run
2 PLC stop
3 PLC reset
start
stop
reset
C2111 GDC Id
g
27012006132510 =
·
Date (day.month.year): 27.01.2006
·
Time (hour:min.:sec.): 13:25:10
Compilation time/date of PLC program
C2113 PLC Prog Name
g
Name of the PLC program
C2115 T−Fct credit
g
Number of technology units
C2116 CreditPinCode 0 Pin code for technology unit activation in the event of
servicing (contact Lenze)
0 {1} 4294967295
C2117 Full credit
g
Service coding
C2118 ParWriteChan. 0 CAN object for L_ParRead and L_ParWrite
0 PDO channel (CAN1_IO ... CAN3_IO)
1 SDO2 channel
