9300 Servo PLC
System blocks
2.12
MCTRL_MotorControl (node number 131)
2−69
L
9300 Servo PLC EN 5.1
Code
IMPORTANT
Possible settings
LCD
Code
IMPORTANT
Selection
Lenze
LCD
[C0084] Mot Rs
à
Stator resistance of the motor
à
Dependent on C0086
·
If C0086 is changed, the value is
reset to the assigned Lenze setting
·
Change sets C0086 = 0
0.00
{0.01
W}
100.00
[C0085] Mot Ls
à
Leakage inductance of the motor
à
Dependent on C0086
·
If C0086 is changed, the value is
reset to the assigned Lenze setting
·
Change sets C0086 = 0
0.00
{0.01 mH}
200.00
[C0087] Mot speed
à
Rated motor speed
à
Dependent on C0086
·
If C0086 is changed, the value is
reset to the assigned Lenze setting
·
Change sets C0086 = 0
300
{1 rpm}
16000
[C0088] Mot current
à
Rated motor current
à
Dependent on C0086
·
If C0086 is changed, the value is
reset to the assigned Lenze setting
·
Change sets C0086 = 0
0.5
{0.1 A}
500.0
[C0089] Mot frequency
à
Rated motor frequency
à
Dependent on C0086
·
If C0086 is changed, the value is
reset to the assigned Lenze setting
·
Change sets C0086 = 0
10
{1 Hz}
1000
[C0090] Mot voltage
à
Rated motor voltage
à
Dependent on C0086
·
If C0086 is changed, the value is
reset to the assigned Lenze setting
·
Change sets C0086 = 0
50
{1 V}
500
[C0091] Mot cos phi
à
Motor cos
j
à
Dependent on C0086
·
If C0086 is changed, the value is
reset to the assigned Lenze setting
·
Change sets C0086 = 0
0.50
{0.01}
1.00
C0111 Rr tune
100 %
Adjustment of the rotor resistance
(Particularly recommended for
non−Lenze motors and high field
weakening.)
·
Adjustment in % of the rated rotor
resistance of the motor.
50.00
{0.01 %}
199.99
