3.6
Code table
9300 Servo PLC
Appendix
3−136
L
9300 Servo PLC EN 5.1
Code
Information
Possible settings
LCD
Code
Information
Selection
Lenze
LCD
C0383 LifeTimeFact.
0
System bus: Node guarding (slave): NodeLifeTime factor
Factor for the NodeLifeTime monitoring time:
NodeLifeTime = C0383 x C0382 (NodeGuardTime)
·
Only relevant for setting C0352 = 4.
·
Additional information about the "node guarding"
function can be found in the Manual for the function
library LenzeCanDSxDrv.lib.
0
{1}
255
C0384 Err NodeGuard
3
System bus: Node guarding (slave):
Response to a "node guarding" event.
·
Only relevant for setting C0352 = 4.
·
Additional information about the "node guarding"
function can be found in the Manual for the function
library LenzeCanDSxDrv.lib.
0
TRIP
1
Message
2
Warning
3
Off
4
FAIL−QSP
C0400 DIS: OUT
g
Analog input terminal 1/2 (AIN1_nIn_a)
−199.99
{0.01 %}
199.99
C0405 DIS: OUT
g
Analog input terminal 3/4 (AIN2_nIn_a)
−199.99
{0.01 %}
199.99
[C0416] Resolver adj
0
Correction of the resolver error
·
For Lenze motors:
Read resolver error from the nameplate
0
{1}
99999999
[C0420] Encoder const
512
Encoder: Constant for encoder input X8
1
{1 inc/rev}
8192
[C0421] Enc voltage
5.00
Encoder: Supply voltage for the encoder
·
CAUTION: Incorrect input may destroy the encoder
5.00
{0.1 V}
8.00
C0425 DFIN const
3
Digital frequency input DFIN_IO_DigitalFrequency:
Increments of the encoder input
0
256 increments per revolution
1
512 increments per revolution
2
1024 increments per revolution
3
2048 increments per revolution
4
4096 increments per revolution
5
8192 increments per revolution
6
16384 increments per revolution
C0426 DIS: OUT
g
Digital frequency input DFIN_IO_DigitalFrequency:
DFIN_nIn_v
−32767
{1 rpm}
32767
C0427 DFIN function
0
Digital frequency input DFIN_IO_DigitalFrequency:
Type of the digital frequency signal
0
2 phases
1
A = Speed / B = Direction
2
A or B = Speed or direction
C0428 DFIN TP sel.
0
Digital frequency input DFIN_IO_DigitalFrequency:
Touch probe selection
0
Touch probe via zero pulse
1
Touch probe through digital input X5/E5
C0429 TP delay
0
Digital frequency input DFIN_IO_DigitalFrequency:
Touch probe delay
·
Compensation of delay times of the TP signal source at
X5/E5
−32767
{1 inc}
32767
