Page 65: 6 maximum speed

9300 Servo PLC
System blocks
2.12
MCTRL_MotorControl (node number 131)
2−59
L
9300 Servo PLC EN 5.1
2.12.6
Maximum speed
The maximum speed (n
max
) is set under C0011. This value is used as a reference for the absolute and
relative setpoints selected for the acceleration and deceleration times and for the upper and lower
speed limits.
·
n
max
= 100 %
º
(INT) 16384
Code
LCD
Possible settings
Info
Lenze
Selection
C0011 Nmax
3000
Maximum speed
Reference value for the absolute and
relative setpoint selection for the
acceleration and deceleration times.
·
For parameterisation via interface:
Large changes in one step should
only be made when the controller
is inhibited.
500
{1 rpm}
16000
Tip!
MCTRL_nNmaxC11 displays the maximum speed set under C0011.
·
Use this system variable for programming your own speed scalings.
·
Example: C0011 = 3000 rpm
ð
MCTRL_nNmaxC11 = 3000
