AT-S63 Management Software Menus Interface User’s Guide
Section III: Using the Command Line Interface 339
Port Mirroring Example
To configure port 8 as the mirroring port and port 6 as the mirrored port you
need to first access the Interface Configuration mode, specify the port, and
then configure the port mirroring feature. Perform the following procedure.
1. From the User EXEC mode, enter:
enable
You now have access to the Privileged EXEC Configuration mode
as indicated by the Switch(config)# prompt.
2. From the Privileged EXEC Configuration mode, enter:
configure
You now have access to the Global Configuration mode as
indicated by the Switch(config)# prompt.
3. Access port 8 on the Interface Configuration mode:
interface Ethernet1/8
You now have access to the Interface Configuration mode as
indicated by the Switch(config-if)# prompt.
4. Enter the port mirroring command, making port 6 the mirrored port:
Switch# port mirror 6
PING Pings a specified IP address to check connectivity to
another system.
PORT Sets port mirroring parameters.
PVID Sets the PVID.
SHUTDOWN Disables a port.
SPANNING-
TREE Sets the parameters for the STP feature.
SPEED-
DUPLEX Sets the speed and duplex mode for a port.
Table 15. Interface Configuration Command Mode Commands
Commands Description
