AT-S81 Management Software User’s Guide
Section I: Using the Menus Interface 125
The VLAN Port Configuration Menu is shown in Figure 29 on page 122
4. Type V to select Set Port VID.
The following prompt is displayed:
Set PVID->Enter port number
5. Type the number of the port whose PVID value you want to configure.
You can configure only one port at a time.
The following prompt is displayed:
Enter PVID for port n
6. Enter the new PVID for the port. The PVID should equal the VID of the
VLAN where you want the port to be an untagged member.
Note
If you specify a PVID that does not correspond to any VIDs on the
switch, the management software creates a new VLAN with a VID
that equals the PVID. The VLAN is not assigned any name.
7. Repeat steps 4 through 6 to configure additional ports.
Restricting
Management
VLAN Access
Management access can be restricted to the default vlan (VLAN 1) or
made available on any vlan. This feature is activated when you select
ENABLE in the Management VLAN field. If this field is set to DISABLED,
the management access is available on any vlan.
To set the Management access value, perform the following procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
The Advanced Switch Configuration Menu is shown in Figure 21 on
page 87.
2. From the Advanced Switch Configuration Menu, type V to select VLAN
Management.
The VLAN Management Menu is shown in Figure 29 on page 122.
3. Type M to select Set Management VLAN.
4. Select E for enable to restrict the management access to the default
vlan (VLAN 1) only or D for disable to allow management access on
any vlan.
