AT-S81 Management Software User’s Guide
Section I: Using the Menus Interface 127
The Config VLAN Member Menu is shown in Figure 31.
Figure 31. Config VLAN Member Menu
The menu displays the following information:
VLAN ID
The VID number of the VLAN.
VLAN Name
The name of the VLAN.
Port
The ports of the VLAN.
Tagging
Whether a port is a tagged or untagged member of the VLAN. An
untagged port is designated with No and a tagged port with Yes.
The selections in this Config VLAN Member menu are explained in
“Modifying a VLAN” on page 128.
AT-8000/8POE Local Management System
VLAN Management -> Config VLAN Member
VLAN ID : 3 VLAN Name: Marketing
Port Tagging
----------------------------------------------------------------------
4 No
5 No
6 Yes
7 No
8 No
----------------------- ------------------------------------
[N]ext Page
[C]hange VLAN Name [A]dd VLAN Member
[P]revious page [R]emove VLAN Member [Q]uit to Previous Menu
Command>
