AT-S81 Management Software User’s Guide
Section I: Using the Menus Interface 137
Mapping CoS Priorities to Egress Queues
This procedure explains how to change the default mappings of CoS
priorities to egress priority queues, shown in Table 5 on page 135. This is
set at the switch level and applies to all ports. This procedure also enables
and disables QoS.
To change the mappings, perform the following procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
The Advanced Switch Configuration Menu is shown in Figure 21 on
page 87.
2. From the Advanced Switch Configuration Menu, type S to select
Quality of Service Configuration.
The Quality of Service Configuration Menu is shown in Figure 33.
Figure 33. Quality of Service Configuration Menu
AT-8000/8POE Local Management System
Advanced Switch Configuration -> Quality of Service Configuration Menu
[T]raffic Class Configuration
[P]ort Priority Configuration
[Q]uit to previous menu
Command>
