Chapter 11: IGMP Snooping
150 Section I: Using the Menus Interface
Viewing the Multicast Groups
To view the IGMP snooping multicast groups, perform the following
procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
The Advanced Switch Configuration Menu is shown in Figure 4 on
page 32.
2. From the Advanced Switch Configuration Menu, type I to select IGMP
Snooping Configuration.
The IGMP Configuration Menu is shown in Figure 36 on page 148.
3. Start your viewing application.
4. Type V to select View group members.
The following prompt is displayed:
Enter VLAN ID>
5. Enter the VLAN ID number.
The menu is updated to show the MAC address of the multicast group,
as shown in Figure 37
Figure 37. MAC Address DIsplayed on IGMP Configuration Menu
AT-8000/8POE Local Management System
Advanced Switch Configuration -> IGMP Configuration Menu
IGMP Snooping Status:Disabled
IGMP Snooping Age-Out Timer:280 seconds
VLAN ID Multicast group address
------- ------------------------
1 01:00:5E:7F:FF:FA
----------------------- -----------------------------
[N]ext Page
[E]nable/Disable IGMP Snooping
[P]revious Page [S]et Age-Out Timer
[V]iew group members [Q]uit to previous menu
Command>
