AT-S81 Management Software User’s Guide
Section I: Using the Menus Interface 107
Configuring PoE
This section contains the following procedures:
 “Displaying the PoE Configuration,” next
 “Changing the PoE Port’s Admin Setting” on page 108
 “Setting the PoE Port’s Priority” on page 109
Displaying the
PoE
Configuration
To display the current PoE Configuration, perform the following procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
The Advanced Switch Configuration Menu is shown in Figure 21 on
page 87.
2. From the Advanced Switch Configuration menu, type E to select
Power Over Ethernet.
The Power Over Ethernet menu is shown in Figure 26.
Figure 26. Power Over Ethernet Menu
The Power Over Ethernet Configuration menu displays information
about the PoE status of each port and also allows you to configure the
AT-8000/8POE Local Management System
Advanced Switch Configuration -> Power Over Ethernet Menu
Power Budget : 95W
Power Consumption : 21W
NO. Admin Status Class Priority Pow.(mW) Vol.(V) Cur.(mA)
--- ----- -------------- ----- -------- -------- ------- --------
1 Up Powered 0 Low 0 0 0
2 Up Not Powered 0 Low 0 0 0
3 UP Powered 0 Critical 8290 60 137
4 Up Not Powered 0 Low 0 0 0
5 Up Powered 0 High 15853 49 320
6 Up Not Powered 0 Low 0 0 0
7 Up Not Powered 0 Low 0 0 0
8 Up Not Powered 0 Low 0 0 0
----------------------------------------------------------------
Set PoE Port Admin [S]tatus
Set PoE Port Pr[i]ority
[Q]uit to previous menu
Command>
