Figure 44: tightening the rack mount screws – Allied Telesis SwitchBlade x3106 User Manual
Page 91
SwitchBlade x3106 Installation Guide
91
5. Tighten all six screws shown in Figure 44 to secure the chassis to the
equipment rack, Allied Telesis recommends tightening the screws to
10 inch-lbs.
Figure 44. Tightening the Rack Mount Screws
6. Go to “Removing the Shipping Brace” on page 92.
Screws
Screws
