1000base-t connector pinouts – Allied Telesis SwitchBlade x3106 User Manual
Page 259
SwitchBlade x3106 Installation Guide
259
Table 43 lists the pin signals when a 10/100/1000Base-T port is operating
at 1000 Mbps.
Table 43. 1000Base-T Connector Pinouts
Pin
Pair
Signal
1
1
TX and RX+
2
1
TX and RX-
3
2
TX and RX+
4
3
TX and RX+
5
3
TX and RX-
6
2
TX and RX-
7
4
TX and RX+
8
4
TX and RX-
