SwitchBlade x3106 Installation Guide
55
SBx STATUS
LEDs
The SBx STATUS LEDs display general status information about the
Ethernet line cards and controller cards, as described in Table 13 on
page 56. There are twelve LEDs, number 0 to 11. However, only LEDs 0
to 5 are active because the AT-SBx3106 Chassis has only six slots. LEDs
6 to 11 are not used. If the chassis has two controller cards, the SBx
Status LEDs on both cards are active.
Table 12. SYS (System) Status LEDs
LED State Description
M/S
Solid Green The AT-SBx31CFC Central Fabric Controller
card is the active master controller card in the
chassis.
Solid Amber The controller card is the inactive master card or
was disabled with the management software.
Flashing
Amber The controller card is initializing its management
software or synchronizing its database with the
active master card.
PSU
Solid Green The power supplies are operating properly.
Flashing
Amber A power supply is experiencing a problem.
Possible causes are:
 The input AC voltage from a power source is
not within the normal operating range of a
power supply module.
 The output DC voltage from a power supply
module to the line cards is not within the
normal operating range.
 A power supply is experiencing high
temperature.
 A power supply has failed.
Check the status LEDs on the individual power
supply modules to determine which module has a
fault condition.
FAN
Solid Green The fan module is operating properly.
Flashing
Amber The fan module has a problem. A fan is operating
below the normal operating range or has
stopped.
