Page 188
Chapter 7: Powering On the Chassis
188
Figure 143. Connecting the Positive Wire
6. Wrap the negative lead wire clockwise around the remaining terminal
screw and secure the screw and wire to the negative terminal
connection on the terminal block with a #3 Phillips-head screwdriver,
as shown in Figure 144 on page 189. The negative terminal is on the
right.
