Figure 121: installing the grounding wire – Allied Telesis SwitchBlade x3106 User Manual
Page 171
SwitchBlade x3106 Installation Guide
171
Figure 121. Installing the Grounding Wire
5. Connect the other end of the grounding wire to the building protective
earth.
Warning
When installing this equipment, always ensure that the power supply
ground connection is installed first and disconnected last. E11
Note
This system will work with a positive grounded or negative grounded
DC system. E13
Grounding
wire
