SwitchBlade x3106 Installation Guide
243
7. Install the new controller card. For instructions, refer to “Installing the
AT-SBx31CFC Controller Fabric Card” on page 118.
8. Start a management session on the chassis.
9. At the command prompt, enter the ENABLE CARD command to
enable the new controller card: Here is the command:
enable card=inactcfc
10. Log off to end your management session.
To remove a controller card from the chassis, perform the following
procedure:
1. Disconnect the cables from the NET MGMT and Console ports on the
controller card.
2. Use a #2 Phillips-head screwdriver to loosen the two screws on the
faceplate of the card.
3. Carefully pull out the handles of the faceplate to disconnect the
controller card from the connector on the backplane of the chassis.
4. Carefully slide the controller card from the chassis.
Caution
Keep the card level as you slide it out of the chassis. You might
damage the components on the top or bottom of the card if you slide
it out at an angle. Refer to Figure 70 on page 117.
5. Do one of the following:
 For instructions on how to install a new controller card in the
chassis, refer to “Installing the AT-SBx31CFC Controller Fabric
Card” on page 118.
 If you do not plan to immediately install another controller card in
the slot, cover the slot with a blank cover. For instructions, refer to
“Installing the Blank Slot Covers” on page 128.
 If you do not plan to immediately install the controller card in
another chassis, continue with this procedure.
6. Store the controller card in an anti-static bag.
7. Return the card to its shipping container.
