KEW6315 Possible recording time
KEW6315 - 76 -
“Time period recording”
Measured data will be recorded at the preset interval for the specified time period of the selected period. When
the specified time comes, a recording will start and end automatically; such a recording cycle will be repeated
everyday during the specified period. Please refer to “(8)/ (9) Setting for recording method” (P. 45).
Selection
REC Period Start-Stop Day/ Month/ Year (DD/ MM/ YYYY) - Day/ Month/ Year (DD/ MM/ YYYY)
REC Time Start-Stop Hour:Minute (hh:mm) - Hour:Minute(hh:mm)
Move the blue highlight to “REC Period”. Show the value entry window.
Specify the time and date. Confirm. Cancel. Move the blue highlight to
“REC Time. Show the value entry window. Specify the time and date.
Confirm. Cancel.
Possible recording time
When the 2GB of SD is used:
Interval
REC item
Interval
REC item
Power +Harmonics Power +Harmonics
1sec 13days 3days 1min 1-year or more 3months
2sec 15days 3days 2min 2-year or more 6months
5sec 38days 7days 5min 6-year or more 1-year or more
10sec 2.5months 15days 10min
10-year or more
2-year or more
15sec 3.5months 23days 15min 3-year or more
20sec 5months 1month 20min 5-year or more
30sec 7.5months 1.5months 30min 7-year or more
1hour
10-year or more
2hours
150/180-cycle 23days 4days
* Data of power quality events are not considered to estimate the possible recording time. The max possible
recording time will be shortened by recording such events. The max file size per recording is 1GB.
* Please ensure to use the SD cards provided with this instrument or as optional parts.
