KEW6315 Items measured at Integration measurement
KEW6315 - 140 -
Items measured at Integration measurement
Power consumption (if P>0）
Active power energy +WP [Wh]
Displayed digit 6-digit, Unit: m, k, M, G, T (harmonized with
WS
+
)
Display area 0.00000mWh - 9999.99TWh (harmonized with
WS
+
)
* “OL” is displayed when the display area is exceeded.
Equation
( )






+ = +
∑
i
ci
P
h
WPc
1
h: integration period (3600 sec), c: Measurment channel, i: Data point no.
1P2W-1 to 4 +WP
1
, +WP
2
, +WP
3
, +WP
4
, +WP
sum
1P3W(3P3W)-1
to 2
+WP
1
, +WP
2
, +WP
sum1
+WP
3
, +WP
4
, +WP
sum2
+WP
sum
3P3W3A(3P4W) +WP
1
, +WP
2
, +WP
3
, +WP
sum
Apparent power energy +WS [VAh]
Displayed digit 6-digit, Unit: m, k, M, G, T (harmonized with
WS
+
)
Display area 0.00000mVAh - 9999.99TVAh (harmonized with
WS
+
)
* “OL” is displayed when the display area is exceeded.
Equation
( )






= +
∑
i
ci
S
h
WSc
1
h: integration period (3600 sec), c: Measurment channel, i: Data point no.
1P2W-1 to 4 +WS
1
, +WS
2
, +WS
3
, +WS
4
, +WS
sum
1P3W(3P3W)-1 to
2
+WS
1
, +WS
2
, +WS
sum1
+WS
3
, +WS
4
, +WS
sum2
+WS
sum
3P3W3A(3P4W) +WS
1
, +WS
2
, +WS
3
, +WS
sum
Saved item Apparent power energy
